Description
- All-terrain tracked design suitable for uneven and soft surfaces where wheeled lifts struggle.
- 90° platform rotation helps you position the platform for easier access without repositioning the whole machine.
- Extendable platform decks increase working area up to ~6 m for improved reach and productivity.
- Proportional dual joystick controls deliver responsive and smooth operation.
- Automatic and manual levelling for safe working even on sloped ground.
- Built to meet or exceed EN280:2010 safety standards with lockable compartments for hydraulic, electrical and diesel components.
This combination of features makes the Omega 505TS a strong choice for users needing a compact rough terrain scissor lift with excellent platform flexibility and dependable performance.
Typical Use Cases
- Polytunnel & greenhouse builds and maintenance
- Agricultural and horticultural access work
- Outdoor construction and refurbishment
- Site maintenance on uneven terrain
- Industrial projects requiring flexible vertical access
Here’s a practical overview of the core technical data you’ll need before booking:
- Maximum working height: 10.5 m
- Maximum platform height: 8.5 m
- Platform length (retracted): 3.5 m
- Platform length (extended): ~6.0 m
- Platform width: 1.7 m
- Machine length: 3.5 m
- Machine width: 1.8 m
- Stowed height (top guardrails): 2.82 m
- Stowed height (guardrails lowered): 2.47 m
- Stowed height (guardrails removed): 1.66 m
- Weight: ~5,200 kg
- Ground clearance: 330 mm
- Lifting capacity: 500 kg
- Drive type: Tracked undercarriage
- Maximum drive speed: ~2.2 km/h
- Slow drive speed: ~0.8 km/h
- Gradeability: ~45 %
- Platform rotation: 90°
- Diesel engine: Kubota V1505
These specifications make the Omega 505TS ideal where a compact tracked scissor lift with good reach and flexibility is needed on uneven sites.
When you choose Northern Polytunnels for your tracked scissor lift hire, you benefit from:
- Well-maintained equipment ready for site work
- Expert advice on machine suitability and logistics
- Delivery options across the UK
- Transparent hire terms and support
Whether it’s rough terrain scissor lift hire, all terrain scissor lift hire or heavy-duty access for construction and agriculture, the Omega 612TS delivers the performance and reliability your project demands.
